| H4 |
Lift Open Height |
2567 mm |
| H3 |
Lifting Height |
2000 mm |
| H2 |
Free Lifting |
100 mm |
| H1 |
Lift Closed Height |
1520 mm |
| I |
Fork Length |
1115 mm |
| Q |
Lifting Capacity |
1500 kg |
| S |
Fork Thickness |
60 mm |
| H14 |
Total Height with Arm |
870/1.200 mm |
| H13 |
Minimum Fork Height |
85 mm |
| H12 |
Wheel Body Distance |
162 mm |
| H11 |
Body Height |
800 mm |
| Y |
Axle Distance |
1384 mm |
| C |
Load Centre |
600 mm |
| % |
Loaded/Unloaded Maximum Slope |
3/10 |
|
B1 |
Width dimension |
800 mm |
|
B10 |
Drive Wheel and Balance Wheel Axle |
526 mm |
|
B11 |
Distance Between Forks |
250 mm |
|
B5 |
Total Fork Width |
570 mm |
|
AST |
Total Length |
1830 mm |
|
E |
Fork Width |
160 mm |
|
X |
Distance Between Axle and Body |
780 mm |
|
N |
Weight |
462 kg |
